Tripp Lite BP480V40 External Battery Pack - 40000 mAh - 240 V DC - Lead Acid - Sealed - 10 Year Maximum Battery Life

Name: BP480V40 External Battery Pack
Brand: Tripp Lite
SKU: BP480V40
Price: 23548.58 USD
Availability: OutOfStock

SKU: BP480V40|Out of Stock

$12,772.65$23,548.58-46%

You save $10,775.93

Quantity

Free Shipping

Warranty Included

30-Day Returns

Out of Stock

Warehouse Location	Available
UPSANDBATTERY	Not Available
Total:	Not Available

Live real-time inventory is delayed by 30 minutes.

About This Product

ManufacturerTripp Lite by Eaton

Battery TypeLead Acid

Nominal Voltage240 V DC

Warranty1 Year

Product Description

Product Details

Superior Performance

High-rate discharge series batteries deliver high discharge rates and rapid recharge times, ensuring your UPS responds instantly during a power outage.

High-Quality Construction

Built using only the highest quality materials and manufacturing processes, durable, long-lasting, and engineered to withstand high-performance UPS demands.

Enhanced Reliability

Consistent, predictable performance means your UPS is always ready when you need it. Equipment stays protected from outages and surges.

Better than General Purpose

Higher discharge rates, faster recharge times, and superior reliability over standard general-purpose batteries.

Quality & Service Guaranteed

Backed by a 1-year warranty. Expert support team available to answer any questions. 30-day money-back guarantee.

Tripp Lite's BP480V200 External Battery Pack offers extended battery runtime when used in conjunction with compatible Tripp Lite UPS systems. Includes internal disconnect for battery isolation.
Compatible UPS Systems: SU40K, SU60K, SU80K, SU20KX, SU40KX, SU60KX, SU80KX, SU60KTV and SU80KTV only.

Features

+/-240VDC Backup Battery Pack Gives Your Compatible UPS System Extended Runtime

The BP480V40 is compatible only with Tripp Lite's 3-phase S3M30KX-NIB, S3M40KX-NIB, S3M60KX, S3M80KX, S3M100KX, S3M120KX, S3M160KX, S3M200KX and other UPS systems that specify the use of this battery pack. The UPS battery pack consists of a steel battery cabinet and 40 sealed 40Ah lead acid batteries. Hardwire installation is safe and simple. Circuit breakers provide overcurrent protection. Internal disconnect for battery isolation is included.

Daisy-Chain Multiple Cabinets for Even Longer Extended-Run Operation

Multiple battery pack cabinets may be connected in parallel to provide the 3-phase UPS system with more runtime. Up to three external battery packs may be connected to the S3M30KX-NIB, S3M40KX-NIB, S3M60KX and S3M80KX. The S3M100KX, S3M120KX, S3M160KX and S3M200KX units can handle as many as seven BP480V40s connected in parallel.

One-Year Warranty

The BP480V40 is backed by a one-year warranty, ensuring reliability and performance.

Technology Highlights

20% Higher Energy Density

High Rate Discharge series achieves 20% higher energy density vs comparable products, through specialized lead calcium alloy formulas and automated manufacturing.

AGM Low Self-Discharge Technology

Low-resistance design enables effortless recharging and maximizes energy output. Absorbent Glass Mat (AGM) retains electrolytes within the mat, reducing leak risk.

Long Life Expectancy

AGM batteries ideal for high current output. Expect long service life when not discharged beyond 60% and fully recharged every 36 months.

Purest Lead Formula

UPSANDBATTERY uses only the highest-grade lead, combined with advanced grid plate recombination technology for maximum efficiency and longevity.

For Bulk Orders

Specifications

Manufacturer	Tripp Lite by Eaton	Brand	Tripp Lite
SKU	BP480V40	MPN	BP480V40
Category	UPS Batteries	Warranty	1 Year
Manufacturer Part Number	BP480V40	Manufacturer Website Address	http://www.tripplite.com
Brand Name	Tripp Lite	Product Model	BP480V40
Product Name	BP480V40 External Battery Pack

Compatible UPS Systems

SU40K, SU60K, SU80K, SU20KX, SU40KX, SU60KX, SU80KX, SU60KTV and SU80KTV only.

Product Type

External Battery Pack

Battery Characteristics	Sealed	Battery Chemistry	Lead Acid
Maximum Battery Life	10 Year	Battery Capacity	40000 mAh
Output Voltage	240 V DC

Height	48.03" (1220 mm)	Width	24.65" (626 mm)
Depth	35.43" (900 mm)	Weight (Approximate)	607.81 kg

Package Contents	BP480V40 External Battery Pack	Compatibility	Tripp Lite S3MX-Series 3-Phase UPS Systems:
Environmentally Friendly	Yes	Environmental Certification	RoHS
Country of Origin	Taiwan

Limited Warranty

1 Year

Key Features & Benefits

Engineered for modern UPS systems that demand more — more discharge rate, more reliability, more uptime. The UR700 compatible replacement is built using only the purest lead and most advanced AGM technology available in the market today.

High Energy Density

20% higher energy density vs comparable products in the same volume range — achieved via specialized lead calcium alloy formula and automated manufacturing processes.

Low Resistance AGM Design

Low internal resistance ensures effortless recharging and maximized energy output. AGM mat technology retains electrolytes, virtually eliminating leak risk.

Advanced Grid Technology

Grid plate recombination technology with special alloys maximizes oxygen and hydrogen recombination during charge/discharge cycles for superior efficiency and longevity.

Industrial-Grade Lead

UPSANDBATTERY uses only the purest and highest-grade lead available — the single biggest differentiator between standard and premium UPS batteries.

1-Year Warranty

Full 1-year warranty on every battery. Expert support team on standby. 30-day money-back guarantee if you're not completely satisfied.

Bulk Pricing Available

Volume discounts for resellers, facilities managers, and enterprise buyers. Call 1-800-748-1102 for custom pricing on orders of 10+ units.
